Schneider Electric Masterpact Nw10 H1 Micrologic 6.0 A Circuit Breaker 1000A

Masterpact NW10 H1 Micrologic 6.0A Circuit Breaker 1000A

The Schneider Electric Masterpact NW10 H1 Micrologic 6.0A Circuit Breaker , a powerhouse of electrical protection designed for robust industrial applications. Manufactured under the well-known Merlin Gerin brand, this circuit breaker stands tall with its advanced Micrologic 6.0A technology, ensuring precise and reliable operation at 1000A current ratings. The Masterpact NW10 H1 excels with a maximum operational voltage (Ui) of 1000V and impulse withstands voltage (Uimp) up to 12kV, making it resilient against electrical surges and ensuring uninterrupted performance even in demanding conditions. It’s impressive Icu rating of 65ka at 690V AC and Ics of 100% Icu underline its ability to handle short-circuit currents effectively, safeguarding both equipment and personnel from potential hazards. Manufactured to comply with IEC 60947-2 standards for AC operations and IEC 60947-3 for AC/DC operations at 50/60Hz, the Masterpact NW10 H1 offers versatility in voltage configurations, supporting both 480V and 690V installations seamlessly. With an Icw rating of 65ka for 1 second and a category B classification, it ensures sustained operation under extreme fault conditions, providing composure in critical industrial contexts.

Designed for efficiency and reliability, this circuit breaker integrates seamlessly into various electrical systems, enhancing operational safety and reducing downtime. The Masterpact NW10 H1 excels in diverse applications, from heavy industrial complexes to commercial installations requiring high-current protection. Its comprehensive range of operational parameters, including MCH 200/240 Vac compatibility and MX-XF 200-250 Vac/Vdc ratings, demonstrates its adaptability across different voltage conditions, catering to the unique needs of various industries all-inclusive.

Schneider Electric Masterpact NW10 H1 Micrologic 6.0A Circuit Breaker represents a top of innovation and reliability in electrical protection. With features like multi-standard compliance, high short-circuit withstand capability, and robust construction, it ensures superior performance and longevity in demanding industrial environments. Whether you're upgrading existing infrastructure or planning new installations, this circuit breaker offers the ideal solution for ensuring electrical safety, efficiency, and operational continuity.

For a variant optimized for 50/60Hz operations, consider the Merlin Gerin/Schneider Electric Masterpact NW10 H1 Circuit Breaker. Manufactured with the same robust Micrologic 6.0A technology and designed to meet global standards, this model offers seamless integration into electrical systems requiring versatile frequency compatibility. With comparable high-current ratings, voltage configurations, and advanced protective features, the Masterpact NW10 H1 Circuit Breaker ensures reliability and performance across various industrial applications.
