Schneider Electric Nw32 H1 Masterpact Micrologic 5.0A Circuit Breaker 3200A

Masterpact Micrologic 5.0A Circuit Breaker 3200A

The Schneider Electric Nw32 H1 Masterpact Micrologic 5.0A Circuit Breaker is an advanced and reliable solution for electrical protection, specifically designed to ensure the highest level of safety and performance in industrial and commercial applications. With a rated current of 3200A and adherence to severe Iec standards 60947-2 and 60947-3, this circuit breaker offers robust functionality and exceptional durability. The Masterpact Nw32 H1 series is manufactured to handle high fault currents, making it ideal for conditions where electrical loads are large and continuous operation is critical. Its impressive short-circuits breaking capacity and thermal stability ensures uninterrupted power delivery and protection against overloads and faults.

Technical Specifications and Performance

The Nw32 H1 Masterpact Micrologic 5.0A Circuit Breaker boasts a variety of technical specifications that enhance its performance and reliability. It operates with a voltage rating (Ui) of 1000V, and an impulse withstand voltage (Uimp) of 12kV. The circuit breaker high breaking capacity, rated at 65kA for 1 second (Icw), and a service short-circuit breaking capacity (Ics) of 100% of the ultimate breaking capacity (Icu), underscore its ability to handle extreme conditions without compromising safety. Additionally, the breaker is categorized under Cat: B, highlighting its superior quality and compliance with international safety standards. This breaker is suitable for both AC and DC applications, operating effectively at frequencies of 50/60Hz and capable of handling AC23A applications up to 690V.

Advanced Micrologic 5.0A Technology

At the core of the Schneider Electric Nw32 H1 is the innovative Micrologic 5.0A technology. This advanced control unit enhances the circuit breakers protective capabilities by offering precise measurements, real-time monitoring, and detailed diagnostic information. The Micrologic 5.0A control unit supports various functions; including overload protection, short-circuit protection, ground fault protection, and more, ensuring comprehensive electrical safety. With the integration of this technology, users benefit from improved operational efficiency, reduced downtime, and extended equipment life. The control unit also facilitates easy configuration and customization, allowing users to tailor the breaker settings to meet specific application requirements.

Applications

The Schneider Electric Nw32 H1 Masterpact Micrologic 5.0A Circuit Breaker is designed for a wide range of applications, from industrial plants and commercial buildings to critical infrastructure projects. Its robust design and high current rating (In: 3200A) make it ideal for heavy-duty electrical systems. The breaker’s compatibility with various mounting and connection options such as model numbers W10527, H1, Gh800017Aa, K11526, 81410 ensures flexibility in installation and maintenance. With a weight of 96 kg, it is a substantial yet manageable component for large-scale electrical setups. The breaker’s ability to provide reliable protection against electrical faults and its adherence to IEC standards make it a preferred choice for long-term safety and performance. Furthermore, the integration of Micrologic 5.0A technology translates to significant operational benefits, including enhanced monitoring capabilities, preventive maintenance, and overall cost savings.

The Schneider Electric Nw32 H1 Masterpact Micrologic 5.0A Circuit Breaker stands out as a top-tier solution for ensuring electrical safety and efficiency in demanding environments. Its combination of advanced technology, robust specifications, and adherence to international standards make it a crucial component for modern electrical systems. Whether you are looking to protect industrial equipment, maintain the integrity of commercial power systems, or safeguard critical infrastructure, this circuit breaker offers the reliability and performance needed to meet the most challenging electrical protection requirements.

For reliable protection and performance in high-demand applications, consider exploring the Schneider Electric Masterpact NW32 H1 Micrologic 5.0A Circuit Breaker 3200A. This product offers robust features and exceptional performance, similar to what you’ll find in the Schneider Electric NW32 H1 Masterpact Micrologic 5.0A Circuit Breaker 3200A. Both options provide advanced protection and operational efficiency, making them ideal for safeguarding critical electrical systems in various industrial setups.
