Merlin Gerin/Schneider Electric Nw25 H1 Circuit Breaker 2500Amp

NW25 H1 Micrologic 2.0A Circuit Breaker 2500Amp

The Merlin Gerin/Schneider Electric NW25 H1 Circuit Breaker is a robust, high-performance solution designed to provide reliable electrical protection in demanding industrial conditions. As part of Schneider Electric admired Masterpact range, this circuit breaker is manufactured to handle high currents up to 2500A, making it an ideal choice for various long-lasting applications. Built to meet stringent international standards, it adheres to IEC 60947-2 and IEC 60947-3, ensuring both safety and performance. At the compassion of the NW25 H1 is the Micrologic 2.0A control unit, which offers advanced monitoring and protection features. This microprocessor-based system enhances the breakers' ability to protect electrical circuits by providing precise, real-time data on electrical parameters. The NW25 H1 has a rated voltage (Ui) of 1000V, and an impulse withstand voltage (Uimp) of 12kV, demonstrating its capability to operate reliably in high-voltage environments. Its interrupting capacity (Icu) ensures that the breaker can handle fault conditions without compromising the safety of the electrical system.



One of the standout features of the NW25 H1 is its high breaking capacity, with an interrupting rating of 65kA for one second. This capability ensures that the breaker can safely interrupt significant fault currents, maintaining the integrity of the electrical system. Additionally, the breaker's Ics rating, which is 100% of its Icu, signifies that it can perform multiple interruptions at its maximum capacity without degradation. This makes the NW25 H1 a highly reliable component for any industrial setup. The NW25 H1 is versatile in its application, supporting both AC and DC systems with its wide operational voltage range. It is rated for use in 200-240V AC systems at frequencies of 50, 60, and 400Hz, and can also operate in 200-250V DC systems. This flexibility makes it suitable for a variety of power systems, including those found in manufacturing plants, power distribution networks, and other critical infrastructure. The breakers AC23A rating at 690V and 2500A highlights its ability to handle motor loads and other inductive circuits, ensuring seamless performance in various applications.

Installation and integration of the NW25 H1 are straightforward, thanks to its retrofit-friendly design. It can easily be incorporated into existing electrical systems, providing an efficient upgrade path that minimizes downtime. The inclusion of the MCH/XM motor mechanism further simplifies the operation by enabling remote control and automation of the breaker, enhancing convenience and operational efficiency. This feature is particularly valuable in modern industrial environments where automation and remote monitoring are increasingly important. The NW25 H1 is designed to withstand the rigors of industrial use, with a sturdy construction that ensures durability and longevity. Weighing 89 kg, it is built to last, providing reliable protection over many years of service.

The Merlin Gerin/Schneider Electric NW25 H1 Circuit Breaker is a powerful and reliable solution for industrial electrical protection. With its advanced Micrologic 2.0A technology, high interrupting capacity, and versatile operational capabilities, it is well-suited for a wide range of applications. Whether used in power distribution, manufacturing, or critical infrastructure, the NW25 H1 provides robust protection and peace of mind, making it an excellent choice for any industrial contexts.

For a high-performance solution in circuit protection, explore this product the Merlin Gerin NW25 H1 Masterpact Circuit Breaker 12kV 2500Amp. This robust circuit breaker offers superior protection and reliability for demanding electrical systems, ensuring optimal performance and safety. Designed to handle high currents and voltages, it is an ideal choice for industrial and commercial applications where robust protection is crucial.
