Merlin Gerin M16 N1 1600Amp Masterpact Circuit Breaker Tf10961000610

Masterpact M16 N1 Tf10961000610 Circuit Breaker

The Merlin Gerin M16 N1 1600Amp Masterpact Circuit Breaker, model Tf10961000610, is a high-capacity device designed for reliable electrical protection in various industrial applications. It operates efficiently within a voltage range of 380V to 690V and is suitable for both 50Hz and 60Hz frequencies. With a maximum current rating of 1600 amps, this circuit breaker is ideal for handling substantial electrical loads, ensuring the safety and functionality of your electrical systems.

Key Features

One of the standout features of the Merlin Gerin M16 N1 circuit breaker is its interrupting capacity. It boasts an ultimate short-circuit breaking capacity (Icu) and service short-circuit breaking capacity (Ics) of 40kA, ensuring it can handle high fault currents without compromising performance. The circuit breaker also features a withstand short-circuit current (Icw) of 40kA for 0.5 seconds, providing robust protection in critical situations. Additionally, it complies with the IEC 947-2 standard, ensuring it meets international safety and performance guidelines. This circuit breaker includes several advanced functionalities to enhance its performance and reliability. The Mx-a Shunt Trip allows for remote tripping of the circuit breaker, while the Xf-e Closing Release enables remote closing. These features provide greater control and flexibility in managing electrical systems. The device operates within a voltage range of 220/250V AC (50/60Hz) and 200/220V DC, making it versatile for various power systems. The JIS/JEC compliance further assures its quality and compatibility with different standards.

The Merlin Gerin M16 N1 circuit breaker is equipped with a motor mechanism Mch-m that operates within 200/240V AC (50/60Hz), facilitating easy and efficient operation. It also includes a spring-charged switch with a rating of 10A at 240V AC, providing additional operational flexibility. The unit weighs 72.900 kg, ensuring stability and durability. For added convenience, it comes with several accessories, including a motor mechanism and a spring-charged switch, which enhance its overall functionality and ease of use. The Merlin Gerin M16 N1 1600Amp Masterpact Circuit Breaker is a reliable and versatile solution for protecting your electrical systems. With its high interrupting capacity, advanced features, and compliance with international standards, it ensures efficient and safe operation in various industrial applications.

For a similar product offering the same reliable performance and advanced features, consider the Merlin Gerin Masterpact M16 H1 Circuit Breaker 1600A. This model also provides robust protection for your electrical systems with a current rating of 1600 amps and includes additional functionalities to enhance control and safety.
